Overview

FILL-IZ 10.000 Series provides custom–made solutions for reliable filling & closing pre–formed containers. Sturdy and proven mechanical design of the machinery within this series enables high speed linear operations.

The machines are built in a format of up to 8 lanes and are offered with double indexing systems which allows for both a fast format size change and a doubling of the machines output.

Thanks to the in-line and highly developed modular principle, the series allows a competitive, detailed and thorough response to the exact request of the customer.

Due to the long period of studying and researching conducted in R&D department, the series satisfies the most crucial needs whether these be demanding hygiene requirements, capacity requirements or the complex requirements of the product itself.

The CE marked FILL-IZ 10.000 series is manufactured by using stainless steel and equipment of high quality in order to provide the most hygenic solution for the required opetations.

Benefits

  • Maximum speed and flexibility with servo controlled drive,
  • Hygenic design,
  • CIP operating system,
  • Special design to provide Easy Maintenance possibility,
  • All used equipments and material are suitable for working in wet environment,
  • Complete stainles steel and food grade material execution,
  • Maximum working security with close cabinet and lockable safety guards,
  • User friendly display shows all functions and possible errors,
  • Production recording possibility to increase machine efficiency,
  • Internet assistance possibility.

Technical Data

Number of Lines Lines 3 8 8×2
Working Width mm 900 1.380 1.380
Working Lenght mm 4.500 4.500 4.500
Capacity-70ml Pcs / Hour 6.000 15.000 25.000
Min. Dosing ml 20 20 20
Max. Dosing ml 1.700 1,700 1.700
Max. Cup Dimensions mm 160 160 160
Max. Cup Height mm 150 150 150

Applications

  • DAIRY

    • Yoghurt
    • Yoghurt with Fruit
    • Diluted Yoghurt
    • Cream
    • Cheese
    • Cream Cheese
    • Mozzarella
    • Labne
    • Curd
    • Butter
    • Kefir
    • Ayran
    • Quark
    • Desserts
    • Multi Fill Desserts
  • FRUIT &VEGETABLES

    • Jam
    • Marmalade
    • Honey
    • Pudding
    • Mousse
    • Chocolate
    • Ketchup
    • Sauces
    • Tomato Paste
    • Mustard
    • Puree
  • FAT & OILS

    • Margarine
    • Shortening
    • Mayonnaise
    • Sunflower Oil
    • Olive Oil
  • MEAL

    • Ready Meals
    • Salads
    • Instant Soup
  • BEVERAGES

    • Fruit Juice
    • Lemonade
    • Shakes
    • Smoothies
    • Coffee
Do you have any question?

Applications

  • DAIRY

    • Yoghurt
    • Yoghurt with Fruit
    • Diluted Yoghurt
    • Cream
    • Cheese
    • Cream Cheese
    • Mozzarella
    • Labne
    • Curd
    • Butter
    • Kefir
    • Ayran
    • Quark
    • Desserts
    • Multi Fill Desserts
  • FRUIT &VEGETABLES

    • Jam
    • Marmalade
    • Honey
    • Pudding
    • Mousse
    • Chocolate
    • Ketchup
    • Sauces
    • Tomato Paste
    • Mustard
    • Puree
  • FAT & OILS

    • Margarine
    • Shortening
    • Mayonnaise
    • Sunflower Oil
    • Olive Oil
  • MEAL

    • Ready Meals
    • Salads
    • Instant Soup
  • BEVERAGES

    • Fruit Juice
    • Lemonade
    • Shakes
    • Smoothies
    • Coffee
Do you have any question?

Options

  • External cup magazine
  • Production Flexibility with the characteristic of double format execuiton
  • Automatic magazine change
  • H2O2 and UV-C cup sterilization
  • CIP Operating system
  • Sterile Pozitive Air
  • Hepa H-14 Filter
  • Burst contro / leakproofing test
  • Sealing and cutting from film reels
  • External cup magazine
  • Integrated cup collection robot
  • External Cup collection robot
  • Automatic viol feeding unit
  • Carton opening and closing units
  • Wrap around cartoning system
  • Filling by Multihead weigher
  • Filling controlled by Flowmeter
  • Volumetric filler controlled by Servo Motor
  • Pneumatic controlled Volumetric Filler
  • Volumetric Filler with reservoir
  • Weight Controlled filler
